MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Trane
  • Model:
  • 020517 - TRANEMO DPA-H-400-16
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Shearing force: 4000 kN.
Total stroke: 315 mm.
Length: 3600 mm.
Width: 2600 mm.
Rapid traverse: 382 mm/s.
Press stroke: 18 mm/s.
Return traverse speeds: 365 mm/s.
Force max s'opposant à la descente: 300 kN.
Stroke length ejector: 250 mm.
Voltage 50 Hz 3x: 380 Volt.
Motor power: 45 kW.
Machine's weight about: 33000 kg.
Height: 6400 mm.
Force du cylindre: 2000 kN.
