MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Aciera
  • Model:
  • 012794 - ACIERA F 4
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Table length: 800 mm.
Table width: 250 mm.
Longitudinal travel (X-axis): 400 mm.
Transversal travel (y axis): 175 mm.
Vertical travel (z axis): 450 mm.
from: 50 t/min.
up to: 360 mm/min.
Taper in spindle: 30 ISO.
longitudinal from: 12 mm/min.
vertical from: 12 mm/min.
Vertical quill travel: 60 mm.
longitudinal: 1.8 m/min.
vertical: 1.8 m/min.
Voltage 50 Hz 3x: 380 Volt.
Motor output: 2.5 CV.
Machine's weight about: 900 kg.
Length: 1200 mm.
Width: 900 mm.
Height: 1600 mm.
