Manufacturer:
Model:
Description:
Or
Reference: 2170044
with magnetic plate Braillon 450x200 mm close poles
| Netweight | 2100 kg |
| Custom position | 8460.2920 |
| Surface of table | 760x200 mm |
| Max. grinding length | 460 mm |
| Max. grinding width with 30 mm grinding-wheel | 230 mm |
| Max. Distance of centres between table and spindle-axis | 520 mm |
| Longitudinal movement of table, hydraulic | 510 mm |
| Transverse feed automatic, electric | 0,6...20 mm/table strike |
| Feed upwards, 1 division on wheel | 0,01 mm |
| Smooth feed upwards, 1 division on wheel | 0,001 mm |
| Grinding-wheel motor power | 2,4 kW |
| Grinding-wheel spindle speed | 2800 min.-1 |
| Grinding-wheel dims. | 300 x 25 x 76 |
| Max. load on table without magnetic plate | 250 kg |
| Standard dimension of magnetic plate | 450x200 mm |
| weight of magnetic plate | 48 kg |
| errors and omissions excepted-data given without obligation | |
