Manufacturer: Kingsland Model:: Multi 95 2 operator steelworker Punches: 27mm through 25mm
57mm through 12mm
160mm largest diameter with optional equipment Shears: 380 x 20mm Flat bar
480 x 15mm Flat bar Crops Angles: 150 x 15mm @ 90 degrees
80 x 10mm @ 45 degrees Crops Bar: 50mm round / square Notches: 13mm thick Optional Extras: Many Extras Available including:
Linear Rails
Sheet Bending
Louvre Punching
Bar Bending
Bolsters for punching Channel / Web /Flanges
ASK FOR DEATAILS TO SUIT YOUR APPLICATION.
Manufacturer: KingslandModel:: Multi 60 2 operator steelworkerPunches: 29mm through 15mm
57mm through 8mm
160mm largest diameter with optional equipmentShears: 230 x 20mm Flat bar
375 x 10mm Flat barCrops Angles: 130 x 13mm @ 90 degrees
70 x 10mm @ 4...
Manufacturer: KingslandModel: Compact 65, Single OperatorCapacity:: 65 tonnePunches:: 30mm diameter through 15mm or 38mm diameter through 12mm
largest hole 110mm diameter with optional equipmentShears Flats:: 200 x 20mm (max thickness)
300 x 15mm (...
Ermak EKN-6 variable rake hydraulic corner notchers have a strong frame with its statically and dynamically rigid steel table and top beam material. T slot top table realizes precise cuttings and there is no need for alignment for different sheet thi...
Hydro-Pneumatic cutting process | Adjustable saw blade travel speed to the profiles | Double hand safety start | Sawblade lubrication | Pneumatic clamps | Standard V cutting set with Pneumatic clamps | Standard Right and left conveyor (V cutting, 3 m...
