MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Model:
  • FPT - STINGER
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • N/A

DESCRIPTION

X - Travel: 1750mm | Y - Travel: 1400mm | Z - Travel: 600mm | Table Length: 1200mm | Table Width: 1000mm | Table load: 5000 | Feed rate X-Axis: 35000mm/min. | Feed rate Y-Axis: 35000mm/min. | Feed rate Z-Axis: 35000mm/min. | Spindle Taper: HSK 63ISO/Bt/Mk | Power on spindle: 25kW | Speeds / ranges: 18000Rpm | ATC / revolver: 30 | Coolant through spindle / Bar: 20 | Number of controlled axis: 5 | Chip conveyor: Yes | Coolantsystem: Yes | Length: 6000mm | Width: 4000mm | Height: 3850mm | Weight: 21000kg
