INFORMATION
Manufacturing origin : Switzerland
Voltage : 380/50/3
Netweight : see below
Custom position : 8458.11 20
TECHNICAL DATA
Capacities
Maximum swing over the carriage : 115 mm
Maximum turning length (as per equipment) : 215...
LIVE TURRET AND C-AXIS
CNC ECS 2302
Height center mm 430
Distance between centers mm 4000
Spindle motor power HP 90
Chip conveyor
automatic spindle Autoblock diam. mm 500
Specifications: CNC : FANUC 0i-TD avec Manual Guide Centre distance : 5 000 mm Swing over bed : 1 000 mm Swing over cross-slide : 720 mm Bed width : 700 mm Spindle bore : 155 mm Spindle speed 3 step gearbox : 40 to 7...
