CEA
07352
Max power KVA 13
Power factor cos 0,97
Secondary no load voltage V 17:41
Current at 100% A 150
Current at 60% A 200
Max rated current at 30% A 300
Adjusting positions n.12
Spot time sec 0,4:4,5
Max wire speed m/min 25
Wire diameter mm 0.6-0...
WELDTRONIC
07354
Absorbed current r.i. 100% V230 20
Absorbed current r.i. 100% V400 11,5
Absorbed power r.i. 100% KVA 7,5
COS-PHI 0,9
Cover fuse A (400 V) 15
Feed cable V 400 4x4
No load voltage 15,4-40,3
Current at 60% 315
Current at 100% 240
Adjust...
CEA
07776
Nominal maximum power kVA 20
Nominal power at 50% duty ccyle 50% kVA 16
Maximum short-circuit power kVA 45.6
Maximum welding power kVA 36.5
Mains voltage frequency HZ 50-60
Secondary open-circuit voltage V 3.5
Maximum short-circuit secondar...
