NILES-SIMMONS
09529
MULTITASKING
Siemens 840 CNC
Diameter on the bench 940 mm
Turning diameter over the entire length 900 mm
Distance between centers 5200 mm
AXIS TRAVEL:
X1 mm 520 (tool1 +12 +532 // tool2 -25 +495)
X2 mm 671 (+19 +690)
Z mm 5185 ( ...
Rolling width: 3050mm | Rolling thickness 3x toproll Ø: 60mm | Rolling thickness 5x toproll Ø: 70mm | Rolling thickness prebending: 50mm | Top Roll Ø: 630mm | Bottom Roll Ø: 600mm | Side roll Ø: 500mm | Number of rolls: 4 | Rolling speed: 0 - 5 ...
INFORMATION
Manufacturing origin : Switzerland
Voltage : 380/50/3
Netweight : see below
Custom position : 8458.11 20
TECHNICAL DATA
Capacities
Maximum swing over the carriage : 115 mm
Maximum turning length (as per equipment) : 215...
MICROCUT
08731
CNC FANUC Oi-MC
TABLE:
Table dimensions mm 1200x500
Max load Kg 1200
STROKES:
X axis mm 1000
Y axis mm 500
Z axis mm 570
SPINDLE:
Cone ISO 40
Tool taper BT/DIN 69871
Speed rpm 10.000
Motor kW 11/15
TOOL CHANGE:
Tool magazine 24 posizio...
LAGUN
09525
CNC SELCA S4045D
TABLE:
Table dimensions mm 2600x800
N. and width T-slots mm 5-22
Distance between T-slots mm 140
Weight on the table Kg 6500
STROKES:
Longitidinal X mm 2500
Cross Y mm 1000
Vertical Z mm 1200
AUTOMATIC HEAD 2,5°:
Spindle...
