MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Kingsland
  • Model:
  • New Kingsland Steelworker Compact 50 5 Station Hydraulic Steelworker 50 tonne
  • Condition:
  • Used
  • YOM:
  • N/A
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • United Kingdom United Kingdom

DESCRIPTION

Manufacturer: Kingsland<br>Model:: Compact 50, Single Operator<br>Capacity:: 50 tonne<br>Punches:: 23mm diameter through 15mm or 38mm diameter through 9mm largest hole 110mm diameter with optional equipment<br>Shears Flats:: 200 x 15mm (max thickness) 300 x 13mm (max width)<br>Crops Angles:: 100 x 10mm @ 90 degrees 70 x 6mm @ 45 degrees<br>Sections:: 35mm dia round bar 30mm square bar<br>Notches:: 10mm thick<br>Optional Extras:: include bar bending, sheet bending and tube notching ask for details.
