MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • CHRISTEN
  • Model:
  • 023233 - CHRISTEN 1-32/100A
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Min. drill capacity: 1 mm.
Max. drill capacity: 32 mm.
Spitzwinkel min.: 60 °.
max.: 180 °.
Diameter of grinding wheel: 150 mm.
Width of the grinding wheel: 40 mm.
Drilling cap. of grind.wheel: 50 mm.
up to: 2800 t/min.
Power: 1 CV.
Machine's weight about: 450 kg.
Length: 800 mm.
Width: 750 mm.
Height: 1300 mm.
+ request more information
