Centre height: 175 mm. Distance between centres: 1000 mm. Workpiece weight on centres max.: 130 kg. Diameter: 400 mm. Width: 2300 mm. Bore: 127 mm. Turret grinding tool holder num. of spindles: 3. Peripheral speed: 35 m/s. Cross travel CNC: 275 mm. Feed speed up: 0.001-5000 mm/min. Rapid feed motion: 5 m/min. Max. travel: 275 mm. Max. grinding length: 1050 mm. Resolution of the scale: mm. from: 0.001 mm/min. up to: 10000 mm/min. taper in spindle: MT: 5. Taper in tailstock:: 3 CM. Tailstock travel of barrel: 35 mm. Max. table angular displacement: 5 °. Voltage 50 Hz 3x: 400 Volt. Grinding spindle motor: 7.5 kW. Total power required: 30 kVA. Machine's weight about: 4800 kg. Length: 4500 mm. Height: 2200 mm.
