MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Elb
  • Model:
  • 022528 - ELB PERFEKT BD 8 SPS
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Table length: 1360 mm.
Table width: 590 mm.
Number of T-channels: 1.
T-channel width: 16 mm.
Grinding length: 800 mm.
Grinding width: 600 mm.
Grinding height: 400 mm.
Table load max.: 900 kg.
Longitudinal travel (X-axis): 900 mm.
Cross travel (z-axis): 540 mm.
Vertical travel (Y-axis): 400 mm.
from: mm/min.
up to: 300 mm/min.
Grinding wheel speeds fix: 1440 t/min.
Diameter of grinding wheel: 400 mm.
Width of the grinding wheel: 100 mm.
Drilling cap. of grind.wheel: 127 mm.
Spindle cone: 60 mm.
Voltage 50 Hz 3x: 400 Volt.
Grinding spindle motor: 20 kW.
Total power required: 18.5 kW.
Machine's weight about: 5400 kg.
Length: 1200 mm.
Width: 600 mm.
Height: 1900 mm.
