MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Model:
  • 022505 - FASTI 2095 - 12/3.5
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Working width: 1270 mm.
Max. sheet thickness at 40kg/mm2: 4 mm.
Adjust.of the top clamping bar: 350 mm.
Adjustment of the lower clamping bar: 80 mm.
Required power top clamping bar: 2 kW.
Required power lower clamping bar: 2 kW.
Voltage 50 Hz 3x: 400 Volt.
Machine's weight about: 1480 kg.
Length: 2310 mm.
Width: 810 mm.
Height: 1500 mm.
+ request more information
