MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • TOS
  • Model:
  • 021733 - TOS BHU25
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Distance between centres: 1000 mm.
Swing diameter: 280 mm.
Max. Longitudinal travel: 1130 mm.
Max. transversal travel: 245 mm.
Diameter: 400 mm.
Width: 1400 mm.
Bore: 127 mm.
grinding wheel width: 63 mm.
Workpiece weight on centres max.: 60 kg.
number (steps): 12.
from: 22 t/min.
up to: 710 t/min.
Angular displacement: +/-60 °.
Swivelling range: 90 °.
Spindle taper: 4 CM.
Taper in tailstock:: 3 CM.
Table angular displacement: +/- 7 °.
Voltage 50 Hz 3x: 380 Volt.
External Grinding wheel motor: 4 kW.
Total power required: 8 kVA.
Machine's weight about: 2500 kg.
Length: 1600 mm.
Height: 1300 mm.
