MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Haas
  • Model:
  • 020888 - HAAS VF-3SSAPC
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Number of axis total: 3.
Table length: 1219 mm.
Table width: 457 mm.
Table load max.: 794 kg.
Longitudinal travel (X-axis): 1016 mm.
Transversal travel (y-axis): 508 mm.
Vertical travel (z axis): 635 mm.
numbers: 2.
Number of tools: 40.
Tool diameter max.: 64 mm.
Diameter with free adjacent pockets: 127 mm.
Tool lenght: 330 mm.
Max. tool-weight: 5.4 kg.
Time of tool changing: 2.8 s.
Distance spindle nose to table: 742 mm.
up to: 12000 t/min.
Work feed rate: 21.2 m/min.
Rapid traverse:: 35.6 m/min.
Air connect: 6 bar.
Voltage 50 Hz 3x: 400 Volt.
Spindle power: 22.4 kW.
Machine's weight about: 6300 kg.
Coolant system: 208 l.
