MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Lizzini
  • Model:
  • 006946 - LIZZINI NO 3
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Centre height: 130 mm.
Distance between centres: 800 mm.
Table length: 1214 mm.
Table width: 140 mm.
Max. grinding diameter: 260 mm.
Max. grinding wheel diamter: 200 mm.
Taper in spindle:: 5 CM.
Work piece spindle speed: 360 t/min.
up to: 4500 t/min.
Voltage 50 Hz 3x: 380 Volt.
Grinding spindle motor: 2 CV.
Machine's weight about: 1100 kg.
Length: 2180 mm.
Width: 1420 mm.
Height: 1760 mm.
Tailstocks: 2 x.
