GIANA
07816
CNC Siemens Sinumerik
Height of center mm 600
Turning diameter on carriage mm 800
Width of bed mm 920
Longitudinal stroke of carriage mm 1000
EQUIPPED WITH
Automatic 4 positions tool post
3 jaws selfcentering chuck mm 630
n. 2 chip convey...
MEP
07348
CUTTING CAPACITY:
-0 degrees Round mm 210, Square mm 200, Rectangle mm 270x200
-45 degrees Sx Round mm 180, Square mm 180, Rectangle mm 180x190
-60 degrees Sx Round mm 100, Square mm 90, Rectangle mm 120x90
BLADE:
-Blade dimensions mm 2750x...
KONDIA
New02734
NUMERIC CONTROL HEIDENHAIN TNC 150
AXIS X MM.600
AXIS Y MM.350
QUILL VERTICAL AXIS Z MM.125
MAX WORKPIECE WEIGHT 225 KG.
TABLE SIZE MM. 700X300
T SLOTS (DISTANCE BETWEEN T SLOTS) 3 (75 MM.)
T SLOTS WIDTH MM.16
2 SPINDLE RANGE MOTOR 2/...
FICEP
08464
CNC HOLE DRILLING TYPE 1003 DZB:
Working profiles Flats-L-U-H
Max drilling diameter 40 mm (R520N / mm2)
Max thickness 50 mm
Max weight 540 kg
SAW MACHINE TYPE SGB 1045:
Cutting capacity at 90 degrees max/min mm 1015x450/80x10
Cutting capa...
