Dovetail Slideways on X, Y and Z Axis.
Turcite on all Slideways and Gibs.
Swivel Control Panel with Integrated DRO- Digital Read Out.
Variable Speed Head with Power Feed Quill and Auto Stop.
X, Column travel: 12.000 mm
Y, Headstock vertical travel: 1.800 mm
Z, Ram 390 x 390 mm, stroke: 1.000 mm
Bed: 13.300 x 1.090 mm
Two axis Head: C-Axes 360° x A-Axes 3°
Spindle taper: ISO 50
Spindle speed: 10 - 4.500 rpm
Spindle motor: 20 kW
Automati...
PROMAC
10083
WITH MOVING COLUMN AND ROTARY TABLE
CNC Control: Heidenhain iTNC530 - HSCI
X-Axis: 6.000 mm
Y-Axis: 2.000 mm
Z-Axis: 1.200 mm
Rapid feed: 30 m/min
Working feed: 20 m/min
With linear axis Table (B-Axis)
Dimensions: 2.000 x 2.000 mm
Load c...
