Pressure total: 500 ton Ram
stroke: 850 mm
Slide adjustment: 350 mm
Shut height (stroke down, adjustment up): 1200 mm
Free frontal opening L-R: 3110 mm
Table surface area : 3000 x 1800 mm
Slide area: 3000 x 1800 mm
Number of strokes:...
{"0":"equipped with security measures counterpressure in table central lubrification rupture disc max dimensions of tooldie which can be fitted: 900 x 600 x 300 mm","1":"Type\/Model: 100 ton","2":"Stocknumber: N.05 14114","3":"Main category: [N] Mech...
