GRAZIOLI
07916
Table dimensions mm 1050x250
Axis X stroke mm 700
Axis Y stroke mm 200
Axis Z stroke mm 300
Horizontal spindle taper ISO 40
Horizontal spindle speed number 12 / rpm 40-1600
Vertical spindle taper ISO 40
Vertical spindle speed rpm 55-24...
KIHEUNG
07564
CNC Heidenhain 530
STROKES:
Longitudinal stroke mm 4100
Cross stroke mm 1000
Vertical stroke mm 1350
TABLE:
Working surface mm 4500x900
Max pemissible load Kg 8000
SPINDLE:
Spindle taper ISO 50
Spindle speeds rpm 4000
Spindle motor powe...
GRAZIANO
08903
Height of center on the bed mm 260
Height of center in the gap mm 330
Distance between center mm 2500
Spindle bore mm 52
Approx. overall dimensions mm 4100x1300x1600h
EQUIPPED WITH:
-Self-centering chuck Pinto DG diam. mm 315
-DRO 3 ax...
