FEELER
09249
CNC SIEMENS SINUMERIK 810D
TABLE:
Table size mm 400x800
T slots mm 18x3x100
Table load capacity Kg 300
AXIS:
X axis mm 610
Y axis mm 500
Z axis mm 505
Distance spindle nose/table mm 135-640
Distance spindle centre/column mm 480
Distance ...
CMT
09670
CNC FAGOR 8055
Height of centers 300 mm
Distance between centers 1500 mm
Swing diameter on the bed 600 mm
Swing diameter on the slide 365 mm
Z-axis longitudinal stroke 1500 mm
Cross X-axis controlled stroke 250/300 mm
Spindle nose C.L. 8''
...
SARO
08219
MOD. SPA 710
height center mm 355
Turning Diametr on bed mm 710
Turnig Diametro on carriage mm 505
Turning Diametro on gap mm 950
Distance between center mm 5000
CAMLOCK C11
spidle bore mm 105
spindle speed N. 23 - rpm 8-1250
carriage stro...
CAMU
06319
CNC ECS 4802
Table diameter 1450 mm
Swing diameter 1650 mm
Turning height 1000 mm
Max working weigth 8000 kg
Motor power 60 kw
Table speed 0-250 rpm
Vertical stroke carriage 1000 mm
Ram section 230x230 mm
Overall dimension
mm 4000 x 5900 x...
