MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • HYDRAP
  • Model:
  • HYDRAP 50 T
  • Condition:
  • Used
  • YOM:
  • 1973
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • Germany Germany

DESCRIPTION

  • Pressure total: 50 ton
  • Stroke: 200 mm
  • Daylight: 650 mm
  • Table surface area : 1.150 x 900 mm
  • Slide area: 1.150 x 900 mm
  • Approach speed: 660 mm / sec
  • Working speed: 33 - 84 mm / sec
  • Return speed: 660 mm / sec
  • Required power: 24 kW
  • Weight of machine approx.: 5 ton
  • Dimensions L x W x H: 2.150 x 1.000 x 3.500 mm
+ request more information
