Number of axis total 4
Drill capacity in steel 28 mm
Threat cutting in steel M 24
Milling capacity 100 cm3/min
Spindle stroke 160 mm
Spindle speeds :stepless
from 50 rpm
up to 7100 rpm
Table length 880 mm...
Spindle Speeds 9.5 to 1560 (18)
Spindle taper No 5 morse
Spindle travel 410mm
Feeds 0.066 to 0.963
Max spindle height spindle to base 70”
Column dia
Graduations metric
Maximum boring length 4000mmSolid boring 15 – 130mmCounter boring up to 250mmMain motor 55kwRotary table 1250mm x 1750mm with 0.1 degree “B” Axis, adjustable 500mm either side of centre for offset boring, programmed throughVDF B630-4000 Table T...
