COMEC
07591
SLIDE INKPRINT
4 COLORS
CONTROL ELECTROPNEUMATIC
Clichè dimension mm 100x200
Ink-tray dimension mm 90
Max printing diam. mm 75
Pad horizontal stroke mm 250
Pad vertical stroke mm 80
Max printing pressure N 1870
Electric power supply Volt...
Table Size 1168 x 457mm. Travels X/Y/Z 1016/457/457mm. Max workpiece Weight 545Kg. Rapids X/Y/X 24/24/19m/min. Min – Max under spindle 101 – 73mm. Spindle motor power 20HP. Max Spindle Speed 8000RPM. Max Spindle Tools Speed 8000RPM. Max Rapid T...
For clamping workpieces that must not be damaged. The clamping surface is grooved and not ribbed. This results in reducing the potential for marking components. The stepped jaw is hardened approx. 0.2 mm deep. The accuracy of the surface with respect...
