KSJ-08H Steel Soft Jaws 8 Inch
Steel serrated soft jaws to suit a 8 Inch power chuck. Jaws are manufactured from 080M15 Steel.
Good Quality of of material allows for machining with a good finish.
For clamping different materials for the optionally three different clamping inserts are available. The use of teeth results in a high surface pressure whereby maximum holding forces are achieved. In the case of wear of the Mastergrip clamping claws ...
Maximum swing 674mm. Maximum machining dia. 380mm. Bar capacity 77mm. Distance between main spindle & sub spindle 538mm. Main spindle nose A2-8. Main spindle speeds 35-4000 rpm. Sub spindle nose A2-6. Sub spindle speeds 35-6000 rpm. 12 station turr...
Swing over bed 680mm. Swing over cross slide 510mm. Maximum turning dia.430mm. Distance between centres 730mm. Spindle speeds 50-4000 rpm. Motor power 30min/continuous 15Kw/11Kw.Spindle bore 73mm. Bar capacity 67mm. 12 station turret. Driven tooling ...
