MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Hauser
  • Model:
  • 023058 - HAUSER S 50 L CNC 400
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Table length: 1320 mm.
Longitudinal travel (X-axis): 1200 mm.
Transversal travel (y-axis): 600 mm.
Travel of the vertical slide: 635 mm.
Passage from grinding motor to table: 750 mm.
Max. grinding diameter: 230 mm.
with display-plate: 360 mm.
Passage between the columns: 950 mm.
up to: 80000 t/min.
from: 9000 t/min.
With air-turbine max.: 160000 t/min.
Voltage 50 Hz 3x: 380 Volt.
Total power required: 9 kVA.
Machine's weight about: 6300 kg.
Length: 3000 mm.
Width: 2500 mm.
Height: 2870 mm.
