Number of axis total: 6. Number of spindles: 2. Number of milling heads: 1. Distance between centres: 1500 mm. Swing diameter: 760 mm. Maximum turning length: 1524 mm. Max. turning diameter: 760 mm. Max. bar diameter: 102 / 77 mm. Tool magazine number of tool places: 40. Tool diameter max.: 90 mm. Diameter with free adjacent pockets: 125 mm. Tool lenght: 400 mm. Spindle nose: A2-8. Internal spindle diameter: 112 mm. C axis (spindle,resolution): °. from: 35 t/min. up to: 3300 t/min. Spindle power: 30 kW. Torque max.: 500 Nm. Spindle hole: 88 mm. max. speed: 35 - 4000 t/min. Power of back spindle: 26 / 22 kW. Milling spindle receptacle: CAPTO C6. Milling cutter speeds: 15 - 12000 t/min. Spindle torque: 120 Nm. Drive milling spindle: 18.5 kW. B axis swivelling range: -30 / +195 °. B axis resolution max.: °. X axis: 630 mm. Y axis: + / - 115 mm. Z axis: 1585 mm. Feeds: 0 - 8000 mm/min. Rapid traverse X: 38 m/min. Rapid traverse Z: 38 m/min. Rapid traverse Y: 26 m/min. Time under power: 35000 Heures. Machine's weight about: 13300 kg. Required floor space: 5110 x 2196 mm. Height: 2798 mm. 3-jaw chuck diameter: Forkhardt 400 mm. 3-jaw chuck diameter (back spindle): Forkhardt 315 mm. Coolant system: 444 l. Coolant through the milling head: 15 bar.
Used Tombstone for CNC Horizontal Machining Centres. Suitable for pallets of 500mm. Steel, Base size 480 x 480mm, plate thickness 100mm, working surface 500 x 500mm x 2, pitch of holes for edge locators 110mm & 150mm, Full grid fixture on one face, n...
