MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Fanuc
  • Model:
  • 021706 - FANUC Robocut Alpha 0C
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Length: 1800 mm.
Width: 1600 mm.
Height: 2000 mm.
Table load max.: 250 kg.
Longitudinal traverse (X-axis): 320 mm.
Cross traverse (Y-axis): 220 mm.
Vertical travel (Z axis): 180 mm.
U axis: 120 mm.
V-axis: 120 mm.
Rapid traverse:: 900 mm/min.
Taper-cut +/-: 30 °.
from: 0.1 mm.
up to: mm.
Max. coil weigth: 6 kg.
Total power required: 11 kVA.
Total volume of dielektric: 390 l.
Voltage 50 Hz 3x: 400 Volt.
Machine's weight about: 1500 kg.
