MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • DISKUS
  • Model:
  • 015805 - DISKUS DDS 457 R
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Work-piece diameter: 5 - 50 mm.
Max. work-piece height: 1 - 70 mm.
outside diameter: 457 mm.
inside diameter: 76 mm.
Width / height: 75 mm.
from: 22 t/min.
up to: 215 t/min.
Voltage: 380 Volt.
Grinding motor power: 2 x 30 kW.
Total installed power: 35 kW.
Machine's weight about: 4000 kg.
Length: 2450 mm.
Width: 1100 mm.
Height: 2700 mm.
Measuring instrument: IONIC.
