Swing over Bed 460mm. Swing over Cross slide 270 mm. Swing in Gap 730 mm. Spindle Centre Height from Floor 1145 mm. Distance between centres 1500mm. Spindle Nose Camlock D-18. Taper in Spindle Nose Bush No 5MT. Spindle Bore 77 mm. Spindle Motor 7.5kW...
INFORMATION
Manufacturing origin : Switzerland
Voltage : 380/50/3
Netweight : see below
Custom position : 8458.11 20
TECHNICAL DATA
Capacities
Maximum swing over the carriage : 115 mm
Maximum turning length (as per equipment) : 215...
