Table dia. 3048mm. Maximum swing 3708mm. Minimum/Maximum under cross rail 914mm/2134mm. Table speeds 1.5 – 39.5 rpm. Feeds 0.10 – 5 2/rev. Motor 45kW (60hp). 1 x Ram Slide and 1 x Turret Slide. Pendant Control. 2 x Newall DP700 Digital readouts. ...
• General renovation 1998
• man. year 1974
• The diameter of the working spindle 90mm
• ISO spindle taper
• Travel in X axis: 1250 mm
• Travel in Y axis: 900 mm
• Travel in the Z axis: 1000 mm
• Spindle stroke (W): 680 mm
• ...
