MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Model:
  • Hedelius - C60 S - 1200
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • N/A

DESCRIPTION

X - Travel: 1200mm | Y - Travel: 620mm | Z - Travel: 520mm | Table Length: 1550mm | Table Width: 600mm | Table load: 1500 | Feed rate X-Axis: 15000mm/min. | Feed rate Y-Axis: 15000mm/min. | Feed rate Z-Axis: 15000mm/min. | Spindle Taper: 40ISO/Bt/Mk | Power on spindle: 18kW | Speeds / ranges: 8000Rpm | ATC / revolver: 30 | Number of controlled axis: 3 | Chip conveyor: Yes | Coolantsystem: Yes | Length: 3500mm | Width: 3000mm | Height: 2900mm | Weight: 9000kg
+ request more information

SEND ENQUIRY

*I AM A
Dealer
End User
Check here if you no longer wish to subscribe to our newsletter.

SHARE PAGE

REQUEST MORE INFORMATION

SEND ENQUIRY

*I AM A
Dealer
End User
Check here if you no longer wish to subscribe to our newsletter.

    Sellers

    Mach4Metal

    • Contact Name
    • Bart Steers
    • Contact Number
    • +31 (0)316 247 123
