LANDONIO
NEW05471
5 AXIS
COLUMN FOUR LINEAR AXIS
ROTARY TABLE AND INDEXING HEAD
CNC HEIDENHAIN iTNC 530 M
STROKES:
Axis X (longitudinal) mm. 3.000
Axis Y (head cross) mm. 1.000
Axis Z (vertical) mm. 2.000
Axis W (upright cross) mm. 1.000
Axis C (rota...
COVEMA
07734
Height of center mm 250
Diameter over the bed mm 500
Diameter over the carriage mm 360
Distace between center mm 1500
Bed widht mm 350
Chuck diam. mm 315 simple guide
Spindle bore mm 105
Spindle speed n.16 - rpm 20:1600
Bar passaging mm ...
INVIMEC
07871
Max diameter on centers mm 200
Max distance between centers mm 550
Table size mm 800x98
Longitudinal travel mm 400
Angular adjustment of table 360 degrees
Vertical adjustment of grinding wheel head mm 145+95
Cross ajustment of grinding...
