This series has extra wide columns to avoid vibration during milling for high speed processing. These highly powered machines are equipped with roller type linear guideways, which offers super high rigidity and loading capacity up to 10 tons.
Travels: 1350 / 700 / 700mm (X, Y, Z) Spindle power 18.5kW BT-50 spindle for heavy cutting (opt BBT-50) Wide base with 4 slideways in Y-axis High torque output of 498Nm 24 (opt 32 or 40) Tool Magazine Maximum part weight 2,200Kg Screw chip removers i...
EUMACH
09972
CNC control HEIDENHAIN iTNC 530 HSCI
5 simultaneous axes
Stroke X axis 1000 mm
Stroke Y axis 800 mm
Stroke Z axis 700 mm
Feed rate on X, Y and Z axes 10000 mm/min
Traversing feeds X, Y and Z axes 24000 mm/min
X axis ball screw, Ø x pitc...
