GRAZIOLI
07266
Height of center mm 250
Distance between center mm 1500
Bed width mm 360
Max turning diameter on bed mm 500
Max turning diameter on carriage mm 318
Gap width mm 270
Spindle nose CAM LOCK 8''
Spindle bore mm 78
Tailstock quill diameter ...
Used BMT55 Angular Driven Tool Holder for CNC Lathes, BMT55, ER25 Collet Chuck, Length of drive to the end of the tang - 103mm, (Suitable for Doosan Lathes)
Bartsch model WT400 Roboflex automated handling six axis Kuka robot on pedestal complete with end of arm tooling and programming unit (to include all product specific work piece holders and tooling, etc.)
Serial No. 20000215/10004136, YoM 2008
