Heavy cutting lathe with spindle nose A2-11 for turning length from 1250mm to 4250mm. Bar capacity 91mm, Spindle speed 2500rpm. Single piece cast slant bed (45-degree) for minimum distance from ball screw to the tool tip Spindle bore A2-11 with hydra...
One piece 30˚ slant bed Large swing diameter 720 mm 8″ Power chuck / 4200 rpm Z-axis travel 600 mm High thrust force 1583 Nm High rapid feed 24/24 m/min (X/Z) Shortened belt driven spindle Rotary operation panel
One piece 30° slant bed Box guideways for increase rigidity 8” Power chuck / 4200 rpm Z-axis travel 400 / 600 mm (S20/40, S20/60) Programmable tailstock Machine width 2300mm only for Vturn-S20/40 with rear disposal chip conveyor High rapid feed 20...
Genuine 45° slant bed for minimum distance from Z-axis ball screw to the tool tip. Box slideways with hardness HRC 55 for heavy cutting. Programmable tailstock and chip conveyor is offered as standard. Only wide range spindle motor Fanuc αPi is ins...
