For clamping different materials for the optionally three different clamping inserts are available. The use of teeth results in a high surface pressure whereby maximum holding forces are achieved. In the case of wear of the Mastergrip clamping claws ...
Punching:Diameter x Maximum Thickness 33mm x 20mm. Maximum Diameter x Thickness mm 57mm x 12mm. Stroke Length 80mm. Throat Depth 355mm. Largest Hole Diameter standard 57mm. Largest Hole Diameter – Optional 160mm.Shearing:Flat Bar – Width x Maximu...
Swing over bed 660mm. Maximum machining dia. 360mm. X travel 225mm. Z travel 1125mm. Rapid feeds X/Z 30/33m/min. Spindle speeds to 35 – 5000 rpm. Spindle nose A2-6. Spindle power (30min/cont rating) 18.5/15 kW. 12 station turret. No. of driven posi...
KSJ-04 Steel serrated soft jaws to suit a 4 Inch power chuck. Jaws are manufactured from 080M15 Steel. Good Quality of material allows for machining with a good finish.Jaw Finder
