Swing over bed 700mm. Swing over carriage 550mm. Between centres 630mm. Max. turning dia. 390mm. Standard turning dia. 264mm. Bar capacity 52mm. Travels X/Y/Z 150 + 35/600/+-45. Max. spindle Speed rpm 5000. Spindle nose (chuck) in A2-6 (8”). Spindl...
For clamping different materials for the optionally three different clamping inserts are available. The use of teeth results in a high surface pressure whereby maximum holding forces are achieved. In the case of wear of the Mastergrip clamping claws ...
