ANNO: 2000
Matricola: AV5C0146
Ore lavoro: 16250
C.N. FANUC
Tavola: n.2 da 860 x 560 mm
Peso ammesso: 2300 Kg
Corse:
Asse X 760 mm
Asse Y 510 mm
Asse Z 570 mm
Avanzamenti in rapido: asse X 40m/min, asse Y 40m/min, asse Z 32 m/min
Avanzamenti: 16 m/mi...
• Suitable for Processing Precision Internal or External Diameter, Face, Taper, Arc and Threading with High Accuracy
• Induction Hardened Bedway
• Spindle is Supported by Precision Bearings
• Suitable for Educational Environments
NAGEL
07400
working diameters
mm 10-45 rpm 240 - 1200
mm 12-60 rpm 160 - 800
mm 16-90 rpm 120 - 600
Max stroke length mm 300
Honing length mm 200
Distance spindle table mm 1150
Distance spingle column (throat) mm 290
Clamping area mm 916 X
Longitudin...
PAMA
07721
FLOOR TYPE
CONVENTIONAL
Travel axis X mm 3000 (longitudinal)
Travel axis Y mm 2000 (vertical)
Spindle travel W mm 300 (diameter 280 mm)
Spindle travel Z mm 800
Spindle diameter mm 110
Spindle nose ISO 50
Spindle speed 30-3000 Rpm, n.3 rang...
