MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Model:
  • PRESS GIGANT G2-800/2 EXPORT
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • N/A

DESCRIPTION

GIGANT 09022 Total press power 800 + 350 tons Pistons: n.2 tons 800 Return power ton 100 Mobile table stroke or piston 1000 mm Max pressure Bar 250 Pump l/mn 260 Moving table approaching speed mm/1'' 300 Moving table working speed mm/1'' 3-9 Mobile table return speed mm/1'' 130 Electric motors: n.1 kW 75 Number of revolutions per minute 1000 Voltage Volt 380/660 Hz 50 Distance max between tables 1600 mm Distance between upright mm 3720 Fixed working table dimensions 3700x2700 mm Mobile table dimensions mm 3700x2700 Blank holder: 6 tons 350 Blank holder stroke 400 mm Max working pressure Bar 240 Table size blank holder mm 3200x2200 Overall dimensions mm 7200x3600x9000 Weight approx. 162000 Kg USED MACHINE
+ request more information
