ONA
09651
TABLE:
Tank size mm 1700x1000x600
Table dimensions mm 1200x800
Max table load Kg 4000
Max height piece mm 530
CROSS TABLE:
Longitudinal X stroke mm 1000
Cross Y stroke mm 600
HEAD:
Electrode-holder stroke 500 mm
Max electrode weight 400 kg
...
