Machine SpecificationsRound TubeMax. Outer Diameter: 254 mm (10")Rectangular ProfileMax. Side Length and Outer Circle Dimeter: 220 mm/ 254 mm (8.66"/10")Max. Raw Length for Automatic LoadingFor Loadmaster Tube 6.5 M: 6500 mm (255.9")For Loadmaster Tu...
Table Dia 320mm. Centre height in vertical 210mm. Centre height in horizontal 240mm. Over all Height in Vertical Without Motor Cover 380mm. Thru-Hole Dia 110mm. Width of T-slot 14mm. Width of Guide Block 18mm. Gear Ratio 1:180/1:90. Min. Indexing Uni...
