MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Elliott
  • Model:
  • 10M Shaping Machine
  • Condition:
  • Used
  • YOM:
  • NA
  • Control:
  • Manual
  • Price:
  • £650 + VAT
  • Country:
  • United Kingdom

DESCRIPTION

Manufacturer Elliott Model 10M 10" Shaping Machine Max Stroke 254 mm (10”) Strokes per min 46-67-85-122 4 Speeds Work Table 258 x 176mm (10 3/16” x 6 15/16””) Top Surface 215 x 190mm (8 ½” x 7 ½”) Side Surface 196mm (7 ¾”) Maximum table to ram 279mm (11”) Longitudinal traverse (max) 187mm (7 3/8”) Vertical traverse 4 cross feeds: .100 – .400mm (.004-.016”) per cut Main Motor: Three Phase Electrics 3/4HP 1.5 amps Approx dimensions 1600 x 965mm 850kg
