NAKAMURA TOME
New04395
CNC FANUC 16 T
Swing over guideways mm 500
Max swing over:
-upper turret mm 330
-lower turret mm 165
Max turning lenght:
-upper turret mm 832
-lower turret mm 782
Distance between spindle nose and turret:
-upper turret min/max ...
FEELER
09684
TABLE:
Table size mm 400x800
T-slots mm 18x3x100
Table load capacity Kg 300
AXIS:
X axis mm 610
Y axis mm 500
Z axis mm 505
Distance spindle nose/table mm 135-640
Distance spindle centre/column mm 480
Distance table /floor mm 865
Distanc...
NESI
09214
UNIVERSAL
LONGITUDINAL TABLE:
Stroke 400 mm
Work table length 800 mm
Work table width mm 105
Workpiece table rotation 360 degree
GRINDING HEAD:
Vertical working stroke 195 mm
Vertical electrospindle movement mm 110
Overall movement 305 mm
...
