SERRMAC
10114
TCU TCS VS DA
CROSS TABLE WITH INC. 45 DEGREES/45 DEGREES
SIMPLE VARIATOR
AUTOMATIC DESCENT
Drilling on steel diam. mm 40
Drilling on cast iron diam. mm 45
Spindle axis conical taper CM 4
Spindle quill diameter mm 72
Spindle quill strok...
LODI
09672
Max longitudinal stroke of the table 920 mm
Max cross stroke 500 mm
Grinding length 800 mm
Grinding width 500 mm
Worktop dimensions 800x450 mm
Distance from the table to the spindle axis 700 mm
Grinding wheel dimensions 400x50x127 mm
Hydra...
