MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Padovani
  • Model:
  • LATHE PADOVANI LABOR 450 CNC
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • N/A

DESCRIPTION

PADOVANI 07420 CAPACITA': Number 2 controlled axis Swing diameter on the bed mm 1050 Max turning diameter on the bed 900 mm Max turning diameter on the carriage 740 mm Max turning length mm 2000 SPINDLE: Spindle nose ASA 15 '' Spindle bore 206 mm Spindle speed rpm 20-1200 Spindle motor (DC) kW 80 SLIDE (X axis) and CARRIAGE (Z axis): Longitudinal movements (Z) 2350 mm Slide movements (X) 575 mm TURRET: Upper turret 6 positions Lower turret 6 positions TAILSTOCK (hydraulic): Quill diameter 150 mm Quill stroke 150 mm Rotating tip inc. CM5 Max quill thrust Kg 3510 BED: Length 3380 mm OVERALL DIMENSIONS AND MACHINE WEIGHT: Overall dimensions mm 6700x2320x2700H Weight Kg 19000 EQUIPPED WITH: AUTOBLOCK 3-jaw hydraulic self-centering chuck diam. 630 mm USED MACHINE
