<h1>CCN LATHE "SCHAUBLIN" TYPE 180-CCN R-TM A2-6</h1>
</div>
<p>
<b>Reference</b>: 2190078
</p>
<p> </p>
<hr>
</section><br/><section id="details">
<h3>Information</h3><table class="table table-striped add_bottom_45"><tbody><tr><td>Manufacturing origin</td><td>Swiss</td></tr><tr><td>Voltage</td><td>380/50/3</td></tr><tr><td>Netweight</td><td>2500 kg</td></tr><tr><td>Custom position</td><td>8458.1120</td></tr></tbody></table><a style="margin-bottom: 25px;" class="btn btn-secondary" data-toggle="collapse" href="#collapse_product_specs" role="button" aria-expanded="false" aria-controls="collapse_product_specs">See more</a><div class="collapse" id="collapse_product_specs"><h3>TECHNICAL DATA</h3><table class="table table-striped add_bottom_45"><tbody><tr><td colspan="2">Capacities :</td></tr><tr><td>Maximum turning diameter</td><td>270 mm</td></tr><tr><td>Maximum swing over carriage</td><td>160 mm</td></tr><tr><td>Height of centres over carriage</td><td>83 mm</td></tr><tr><td>Maximum swing over bed</td><td>430 mm</td></tr><tr><td>Turning length between centres (according to equipment)</td><td>630 mm</td></tr><tr><td colspan="2">Headstock :</td></tr><tr><td colspan="2">Standardized spindle nose, for use of several collets and jaw-chucks by means of adapter sleeves</td></tr><tr><td>Accessories for SCHAUBLIN collets</td><td>B45/F66</td></tr><tr><td>Maximum throughbore, dia.</td><td>36 mm/60 mm</td></tr><tr><td>Diameter of standard chck</td><td>210 mm</td></tr><tr><td>Direct AC motor drive, power at 100%/50% duty factor</td><td>15/18,5 kW</td></tr><tr><td>Max. torque at 100%/50% duty factor</td><td>135/165 Nm</td></tr><tr><td>Spindle speeds, stepless</td><td>4000 min-1</td></tr><tr><td>Spindle positioning increment</td><td>0,1�</td></tr><tr><td colspan="2">C Axis :</td></tr><tr><td>Programmable increment</td><td>0,001�</td></tr><tr><td>Spindle locking</td><td>80 Nm</td></tr><tr><td>Pneumatic closing Cylinder, maximum 5 bar, maximum clamping force</td><td>3400 daN</td></tr><tr><td colspan="2">Apron and carriage :</td></tr><tr><td>Transverse stroke (X-axis)</td><td>230 mm</td></tr><tr><td>Rsolution, on radius</td><td>0,0005 mm</td></tr><tr><td>AC motor drive, torque</td><td>3 Nm</td></tr><tr><td>Ball screw, dia. x pitch</td><td>32 x 5 mm</td></tr><tr><td>Longitudinal stroke (Z-axis)</td><td>720 mm</td></tr><tr><td>Resolution</td><td>0,001 mm</td></tr><tr><td>AC motor drive, torque</td><td>6 Nm</td></tr><tr><td>Ball screw, dia. x pitch</td><td>32 x 10 mm</td></tr><tr><td colspan="2">Feeds :</td></tr><tr><td>Working feeds, X-/Z-axis, stepless</td><td>0-5000 mm/min</td></tr><tr><td>Rapid feed, X-/Z-axis</td><td>8/10 m/min</td></tr><tr><td>Feed pressure, X-/Z-axis</td><td>420/670 daN</td></tr><tr><td colspan="2">Tooling system Turret :</td></tr><tr><td>Number of tool stations</td><td>12</td></tr><tr><td>Number of powered tool stations</td><td>6</td></tr><tr><td>AC motor drive, power in intermittent service</td><td>3,7 kW</td></tr><tr><td>Torque max., intermittent</td><td>36 Nm</td></tr><tr><td>Speed drive, max.</td><td>5000 min-1</td></tr><tr><td>Standardized fixing of toolholders</td><td>VDI 30</td></tr><tr><td>Maximum tool size</td><td>20 x 20 mm</td></tr><tr><td colspan="2">Integrated cooling</td></tr><tr><td colspan="2">Indexing in both senses of rotation</td></tr><tr><td colspan="2">Coolant supply :</td></tr><tr><td>Capacity of coolant tank</td><td>120 litres</td></tr><tr><td>Pump power</td><td>10 l/min</td></tr><tr><td>Pressure</td><td>5 bars</td></tr><tr><td colspan="2">errors and omissions excepted data gived without obligation</td></tr></tbody></table></div>
