T-Slotted Round Base Plate Cast Iron Sub Plate to suit rotary table or indexer. T-Slot pattern to allow for easy flexible set-up of fixturing components.
Ground flat with Locating Holes for precise loading and quick location.
SASS
07450
CAPACITY':
Drilling capacity on steel R = 60 mm 100
Drilling capacity on cast iron 20-22 mm 150
SPINDLE:
Sliding quill diam. mm 110
Cone taper Morse 6
Vertical stroke mm 550
Rotation speed n.32 - rpm 14: 1275
Spindle A.C. motor power - 4...
