TCS
10164
Clamping force 300 ton
Opening force 100 ton
Operating pressure 250 bar
Platen overall dimensions 3,500 x 2,500 mm
Minimum mold size (at max. clamping force) 2,800 x 2,000 mm
Minimum clearance between platens 1,400 mm
Clamping platen height...
MANDELLI
09536
1001 M 14 / U 2500/41KW - 4000
CNC Siemens 840 C
X stroke mm 4000 - longitudinal
Y stroke mm 2500 - vertical
Z stroke mm 2200 - cross
Max workpiece diameter that can be moved 3200 mm
Pallet change - 2 positions - ISO 1250 mm 1250 x 125...
