MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Dunkes
  • Model:
  • DUNKES HZS 250
  • Condition:
  • Used
  • YOM:
  • 1989
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • Germany Germany

DESCRIPTION

  • Press capacity: 250 ton
  • Throat depth: 430 mm
  • Stroke: 300 mm
  • Daylight: 500 mm
  • Table surface area : 1.100 x 850 mm
  • Slide area: 1.100 x 850
  • Table height over floor: 950 mm
  • Approach speed: 330 mm / sec
  • Working speed: 11 - 30 mm / sec
  • Return speed: 330 mm / sec
  • Die cushion capacity in table: 80 ton
  • Die cushion stroke: 100 mm
  • Ejector in ram: 5 ton
  • Ejector stroke in ram: 75 mm
  • Required power: 40 kW
  • Oil volume: 1.400 l
  • Dimensions L x W x H: 3.200 x 2.500 x 4.250 mm
  • Weight of machine approx.: 32 ton
